Technical Capability
| LCD & LCM | Type | Mono TN, STN, FSTN, Color STN, TFT |
| Mother Glass | 370 x 400mm and under |
| Thickness | 0.4, 0.55, 0.7, 1.1mm |
| Pixel Pitch | Minimum 10um |
| Display Mode | Positive and negative |
| Optic Mode | Reflective, transflective, transmissive |
| Color Mode | Yellow green, green, gray, black & white, blue |
| Package Technology | SMT, COB, TAB, COG, COF |
| Connection | Zebra, pin, heat seal, FFC, FPC |
| Backlight | LED, EL, CCFL |
| TFT | Screen Size (diagonal) | 1.8" - 20" |
| Brightness | Up to 1,500 nits |
| Option | Driving board, inverter, touch screen |
Value Added Capability
● Pin headers, connectors and cables
● LED’s
● Controller board, inverter, touch screen
● Open frame, monitor
Production Capacity
| Type | Production Capacity |
| LCD | 370 x 400 Mother Glass | 150K sheets/month |
| LCM | COG | 4M pcs/month |
| TAB | 1.1M pcs/month |
| COB | 1M pcs/month |
| COF | 2.4M pcs/month |
| SMT | 144K pcs/month |
| TFT | 680 x 880 Mother Glass | 15K sheets/month |
| Driving board | 50K pcs/month |
